ISO 7425-2:2021 PDF
Original price was: $65.00.$50.70Current price is: $50.70.
Hydraulic fluid power cylinders — Dimensions and tolerances of housings for elastomer-energized, plastic-faced seals — Part 2: Rod seal housings
This document specifies the dimensions and associated tolerances for a series of hydraulic cylinder rod seal housings to accommodate elastomer-energized, plastic-faced seals used in reciprocating applications.
This document does not stipulate details of seal design, since the manner of construction of seals varies with each manufacturer. The design and material of the seals, and any incorporated anti-extrusion components, are determined by conditions such as temperature and pressure.
This document only applies to the dimensional characteristics of products manufactured in accordance with this document. It does not apply to their functional characteristics.
| Edition | 2021 |
|---|---|
| Standard Part No | 2 |
| Published Date | 2021 |
| Published By | International Standardization Organisation |
| Page Count | 8 |
