ISO 3548-1:2022 PDF
Original price was: $132.00.$102.96Current price is: $102.96.
Plain bearings — Thin-walled half bearings with or without flange — Part 1: Tolerances, design features and methods of test
This document specifies tolerances, design features and test methods for thin-walled half bearings with integral flange up to an outside diameter of Do?=?250?mm and without flange up to an outside diameter of Do?=?500?mm. Due to the variety of design, it is, however, not possible to standardize the dimensions of the half bearings.
Half bearings according to this document are predominantly used in reciprocating machinery and consist of a steel backing and one or more bearing metal layers on the inside.
In reciprocating machinery, flanged half bearings can be used in connection with half bearings without flange.
Alternatively, to serve as a flanged half bearing, it is possible to use a half bearing without flange together with two separate half thrust washers according to ISO?6526, or a half bearing with assembled flanges.
NOTE?????? All dimensions and tolerances are given in millimetres.
| Edition | 2022 |
|---|---|
| Standard Part No | 1 |
| Published Date | 2022 |
| Published By | International Standardization Organisation |
| Page Count | 23 |
