ISO 3245:2015 PDF
Original price was: $65.00.$50.70Current price is: $50.70.
Rolling bearings — Needle roller bearings with drawn cup and without inner ring — Boundary dimensions, geometrical product specifications (GPS) and tolerance values
ISO 3245:2015 specifies the boundary dimensions and preferred dimensions to be used for drawn cup needle roller bearings without inner ring as well as the minimum chamfer dimension limits. Also specified are the closed end thickness dimensions for bearings with one closed end.
In addition, dimensional tolerances for the needle roller complement bore diameter and tolerances for the drawn cup width are specified.
Informative values for the tolerances for shaft raceway and housing bore are given in Annex A.
| Edition | 2015 |
|---|---|
| Published Date | 2015 |
| Published By | International Standardization Organisation |
| Page Count | 11 |
