ISO 10791-10:2022 PDF
Original price was: $177.00.$138.06Current price is: $138.06.
Test conditions for machining centres — Part 10: Evaluation of thermal distortions
This document specifies, tests for the evaluation of thermal distortions of the machine tool structure and positioning system, for machining centres with vertical spindle, with numerically controlled linear axes of lengths up to 5?000?mm for the X-axis and up to 2?000?mm for the Y- and Z-axis. It also applies to machining centres with horizontal spindle with numerically controlled linear axes of lengths up to 5?000?mm for the X-axis, 3?200?mm for the Y-axis and 2?000?mm for the Z-axis.
This document specifies four tests:
—??? environmental temperature variation error;
—??? thermal distortion caused by a rotating spindle;
—??? thermal distortion caused by moving linear axes;
—??? thermal distortion caused by rotary motion of components.
This document is intended to be used with ISO 230-3.
| Edition | 2022 |
|---|---|
| Standard Part No | 10 |
| Published Date | 2022 |
| Published By | International Standardization Organisation |
| Page Count | 44 |
