Optics and photonics — Preparation of drawings for optical elements and systems — Part 16: Diffractive surfaces
This document provides general methods of describing surfaces adding a diffractive optical function on optical surfaces, such as planes, spheres, aspheres or general optical surfaces, in the ISO 10110 series, which standardizes drawing indications for optical elements and systems. The subject of this document is the presentation, description and dimensioning of diffractive surfaces in technical drawings.
This document does not apply to diffractive surfaces with random surface texture, for example stochastic antireflective structures. Also not addressed by this document are all types of 3-dimensionally extended diffractive structures: Bragg gratings, volume holograms (HOE) and acousto-optic modulators.
This document does not address the methods to test and qualify the specifications.
This document does not address tools and methods for manufacturing diffractive surfaces.
| Edition | 2023 |
|---|---|
| Standard Part No | 16 |
| Published Date | 2023 |
| Published By | International Standardization Organisation |
| Page Count | 29 |
